| Throughput per hour, native (uncompressed): | (maximum configuration 2 drives)
LTO Ultrium Gen 1 (15 MB/sec) - 108.0 GB/hr
LTO Ultrium Gen 2 (30 MB/sec) - 216.0 GB/hr
LTO Ultrium Gen 3 (80 MB/sec) - 57.0 GB/hr
SDLT 320 (16 MB/sec) - 115.2 GB/hr
SDLT 600 (36 MB/sec) - 259.2 GB/hr
|
| Audit time: | <2 min
|
| Average cell to drive time: | 10.5 sec
|
| Capacity, native (uncompressed): | (maximum configuration 20 cartridges)
LTO Gen 1 (100 GB/cart) - 2.0 TB
LTO Gen 2 (200 GB/cart) - 4.0 TB
LTO Gen 3 (400 GB/cart) - 8.0 TB
SDLT 320 (160 GB/cart) - 3.2 TB
SDLT 600 (300 GB/cart) - 6.0 TB
|
| Number of cartridge slots: | 10, 20
|
| Number of tape drives / types: | 1-2 LTO Gen 1, 2, 3; SDLT 320, SDLT 600 drives or a combination
|
| Cartridge access port (CAP): | Optional, configurable, single-cartridge slot
|
| Mean exchanges / swaps between failure (MEBF/MSBF): | 2,000,000
|
| Mean time between failures (MTBF): | 360,000 hr (full operation)
|
| Mean time to repair (MTTR): | <30 min
|
| Non-disruptive serviceability: | Hot-swappable drives with power supply and fan, plus Ethernet and serial ports for diagnostics and reporting.
|
| Supported host platforms: | UNIX, Windows NT, Novell NetWare
|
| Robotics control interfaces: | LVD or HVD SCSI
|
| Any Cartridge Any Slot™ technology: | Simultaneous non-partitioned support of multiple tape and media types
|
| Library Admin software: | Remote library monitoring and maintenance (optional)
|
| Library Manager software: | Central management, sharing and robotivs control for SCSI-attached libraries (optional)
|
| Framework Library Monitor software: | Host-based and over SCSI. Monitor and respond to library via leading system management frameworks (SMFs) (optional)
|
| Library Status Tool software: | Embedded software for remote monitoring and diagnostics of entire system
|
| SNMP: | Embedded SNMP agent that enables remote reporting, monitoring and notification via standard Ethernet connection
|
| Digital vision system: | Unique digital vision camera system performs continuous calibration and reads bar codes
|
| Operator panel: | User-friendly configuration and diagnostic controls, status display and viewing window
|
| Automatic clean: | Dedicated cleaning cartridge slot for tape drive cleaning by library or software command
|
| Automatic self discovery: | Self-configures the drives, slots and CAP. Also identifies drive and media types
|
| Continuous automation calibration: | No periodic maintenance or alignment required
|
| Height: | 7.0 in (17.8 cm)
|
| Depth: | 27.5 in (71.1 cm)
|
| Width: | 19.0 in (48.3 cm)
|
| Unit height: | 4u* of standard 19 inch rack space
|
| Weight: | 48.0 lb (21.8 kg)
|
| Temperature (operating): | +50° to +104° F (+10° to +40° C)
|
| Temperature (non-operating): | +50° to +104° F (+10° to +40° C)
|
| Relative humidity (operating): | 20%-80%
|
| Relative humidity (non-operating): | 10%-95%
|
| Voltage: | 100–240 VAC @ 50–60 Hz single phase (auto-ranging)
|
| Library (operating maximum continuous - not peak): | 1.40 A @ 120 V, 0.75 A @ 240 V, 180 V or 0.18 KVA, 615 BTU/hr
|
| Optional internal FC/SCSI router: | 28 VA
|
| Drives: | Drive power consumption varies. Refer to individual drive specifications
|
| Electromagnetic compliance: | EN 50082-1, including IEC 801-2, IEC 801-3, IEC 801-4
VCC Class I
|
| Safety: | CSA standard CAN/CSA-C22.2, no.950-95; UL listed to UL 1950, 3rd Edition; GS licensed to EN 60950, 2nd Edition, 1991 + A1, A2, A3, A4
Nemko, Semko, Demko, Finko certified to EN 60950, (1992) A1/A2/A3/A4/A11, EMKO-TSE (74-SEC) 207/94; CB test certified
|
| Emissions: | FCC #47, part 15, subpart B, class A; VCCI class A European Union CE emissions standards AS/NZS 3548; 1996 (Australia, N.Z.); ICES-003 (Canada)
|
| Immunity: | European Union CE immunity standards
|
