| Throughput per hour, native (uncompressed): | (maximum configurations)
T9840B (6 drives, 19 MB/sec) - 410.4 GB/hr
T9840C (6 drives, 30 MB/sec) - 648 GB/hr
T9940B (6 drives, 30 MB/sec) - 648 GB/hr
LTO Gen 2 (10 drives, 30-35 MB/sec) - Up to 1.26 TB/hr
LTO Gen 3 (10 drives, 68-80 MB/sec) - Up to 2.88 TB/hr
SDLT 320 (10 drives, 16 MB/sec) - 576 GB/hr
SDLT 600 (10 drives, 36 MB/sec) - 1.3 TB/hr
|
| Audit time: | <4 min
|
| Average cell to drive time: | 4.0 sec
|
| Capacity, native (uncompressed): | (maximum configurations 174 cartridges)
T9840B (20 GB/cart) - 3.48 TB
T9840C (40 GB/cart) - 6.96 TB
T9940B (200 GB/cart) - 34.8 TB
LTO Gen 2 (200 GB/cart) - 34.8 TB
LTO Gen 3 (400 GB/cart) - 69.6 TB
SDLT 320 (160 GB/cart) - 27.84 TB
SDLT 600 (300 GB/cart) - 52.2 TB
|
| Number of cartridge slots: | 84, 140, 174 plus six slots for diagnostic/cleaning cartridges
|
| Number of tape drives / types: | 1-6 T9840 or T9940 drives
1-10 LTO Gen 2, Gen 3, SDLT 320 and 600
|
| Cartridge access port (CAP): | Standard, 10-cartridge capacity
Two 5-cartridge removable magazines
|
| Mean exchanges / swaps between failure (MEBF/MSBF): | 2,000,000
|
| Mean time between failures (MTBF): | 360,000 hr (full operation)
|
| Mean time to repair (MTTR): | <30 min
|
| Non-disruptive serviceability: | Hot-swappable drives with power supply and fan, plus Ethernet and serial ports for diagnostics and reporting. Optional Universal Power Supply.
|
| Supported host platforms: | UNIX, Windows NT
|
| Robotics control interfaces: | SCSI-3 media changer command set HVD (default). LVD or HVD SCSI and option of an external FC router
|
| Any Cartridge Any Slot™ technology: | Simultaneous non-partitioned support of multiple tape and media types
|
| Library Admin software: | Remote library monitoring and maintenance (optional)
|
| Library Manager software: | Central management, sharing and robotics control for SCSI-attached libraries (optional)
|
| Framework Library Monitor software: | Host-based and over SCSI. Monitor and respond to library via leading system management frameworks (SMFs) (optional)
|
| Library Status Tool software: | Embedded software for remote monitoring and diagnostics of entire system
|
| SNMP: | Embedded SNMP agent that enables remote reporting, monitoring and notification via standard Ethernet connection
|
| Digital vision system: | Unique digital vision camera system performs continuous calibration and reads bar codes
|
| Operator panel: | User-friendly configuration and diagnostic controls, status display and viewing window
|
| Automatic clean: | Dedicated cleaning cartridge slot for tape drive cleaning by library or software command
|
| Automatic self discovery: | Self configuring for cells, drives and CAPs
|
| Continuous automation calibration: | No periodic maintenance or alignment required
|
| Height: | 65.1 in (165.4 cm)
|
| Depth: | 49.3 in (125.2 cm)
|
| Width: | 28.3 in (71.9 cm)
|
| Unit height: | 6u* of standard 19 inch rack
|
| Weight: | 635.0 lb (288.0 kg)
|
| Temperature (operating): | +59° to +90° F (+15° to +32° C)
|
| Temperature (non-operating): | +50° to +104° F (+10° to +40° C )
|
| Relative humidity (operating): | 20%-80%
|
| Relative humidity (non-operating): | 10%-95%
|
| Voltage: | 100-127 VAC, 200-240 VAC @ 50-60 Hz single phase (auto-ranging)
|
| Library (operating maximum continuous - not peak): | 1.0 A @ 120 V, 0.5 A @ 240 V, 410 BTU/hr
|
| Drives: | Drive power consumption varies. Refer to individual drive specifications
|
| Safety: | CSA standard CAN/CSA-C22.2, no. 950-95; UL listed to UL 1950, 3rd Edition; GS licensed to EN 60950, 2nd Edition, 1991 + A1, A2, A3, A4
Nemko, Semko, Demko, Finko certified to EN 60950, (1992) A1/A2/A3/A4/A11, EMKO-TSE (74-SEC) 207/94; CB test certified
|
| Emissions: | FCC #47, part 15, subpart B, class A; VCCI class A European Union CE emissions standards AS/NZS 3548; 1996 (Australia, N.Z.); ICES-003 (Canada)
|
| Immunity: | European Union CE immunity standards
|
