| Tape load and thread to ready: | 18 sec (formatted)
| 18 sec (formatted)
|
| Average file access time (first file): | 41 sec
| 41 sec
|
| Average access time : | 59 sec
| 59 sec
|
| Maximum/average rewind time: | 90/45 sec
| 90/45 sec
|
| Unload time: | 18 sec
| 18 sec
|
| Data transfer rate, native (uncompressed): | 10 MB/sec
| 30 MB/sec
|
| Data transfer rate (compressed): | 35 MB/sec
| 70 MB/sec
|
| * The actions of the tape drive can be divided into four distinct phases: | | |
| Phase 1: Load time – the amount of time required to insert a cartridge in the drive, load the tape and prepare to read, write or search.: | | |
| Phase 2: Average file access time – the amount of time required to search from the beginning of the tape to the mid-point; does not include load time.: | | |
| Phase 3: Maximum rewind time – the amount of time required to rewind the tape from the end to the beginning of the tape. : | | |
| Phase 4: Unload time – the amount of time required to eject the cartridge from the drive.: | | |
| The average rewind time is the time to rewind a tape from the mid-point to the beginning or one-half of the maximum rewind time.: | | |
| Capacity, native (uncompressed): | 60 GB
| 200 GB
|
| Power on: | 290,000 hr @ 100% duty cycle
| 290,000 hr @ 100% duty cycle
|
| Tape load: | 240,000 hr @ 10 loads/day (100,000 loads)
| 240,000 hr @ 10 loads/day (100,00 loads)
|
| Tape path motion (TPM): | 196,000 hr @ 70% TPM duty cycle
| 196,000 hr @ 70% TPM duty cycle
|
| Head life: | 8.5 yr @ 70% TPM duty cycle
| 8.5 yr @ 70% TPM duty cycle
|
| Uncorrected bit error rate: | 1x10(-18)
| 1x10(-18)
|
| Undetected bit error rate: | 1x10(-33)
| 1x10(-33)
|
| Interface: | 1 Gb Fibre Channel, Ultra-SCSI HVD (40 MB/sec), ESCON 20 MB/sec (maximum)
| 2 Gb Fibre Channel, ESCON, ESCON for VSM, 2Gb FICON for FICON and FICON express channels
|
| Burst transfer rate: | HVD (40 MB/sec)
| |
| Channel rate (Fibre Channel): | 100 MB/sec (maximum instantaneous)
| 200 MB/sec (maximum instantaneous)
|
| Interface (Fibre Channel): |
| N & NL port, FC-PLDA (Hard and soft AL-PA capability), FC-AL-2 FCP-2, FC-TAPE
|
| Read/write compatibility interface: | Proprietary format
| Proprietary format
|
| Emulation modes: | Native, 3490E, 3590
| Native, T9940A, 3490E, 3590
|
| Height: | 5.25 in
| 3.25 (8.25 cm)
|
| Depth: | 25.0 in (63.5 cm)
| 25.0 in (63.5 cm)
|
| Temperature (operating): | +59° to +90° F (+15° to +32° C)
| +59° to +90° F (+15° to +32° C)
|
| Temperature (non-operating): | +50° to +104° F (+10° to +40° C )
| +59° to +90° F (+15° to +32° C)
|
| Relative humidity (operating): | 20%-80%
| 20%-80%
|
| Relative humidity (non-operating): | 10%-95%
| 10%-95%
|
| Voltage: | 100-240 VAC @ 50-60 Hz
| 100-240 VAC @ 50-60 Hz
|
| Power consumption/dissipation (operating maximum continuous - not peak): | 82 VA / 280 BTU/hr
| 82 VA / 280 BTU/hr
|
